IDP Smart-51 Single or Dual Sided ID Card Printer

IDP Smart-51 Single or Dual Sided ID Card Printer

Vendor: IDP View brochure
Low Price Guaranteed

Dual Sided Interface and Encoding

# Name: Qty
651399 USB
651399-651570 USB + Ethernet
651399-651356 USB, Magnetic Stripe Enc. Standard (ISO 7811 (TrackI,II,III Read/Write), Hi-Co / Lo-Co Enc.)
651399-651358 USB, Magnetic Stripe Enc. Upper (ISO 7811 (TrackI,II,III Read/Write), Hi-Co / Lo-Co Enc.)
651399-651359 USB, Contact SmartCard Enc. (Internal) ISO 7816 (ID-1)
651399-651360 Contactless SmartCard Enc. (Internal, 13.56Mhz) ISO 14443 (Type A/B), MIFARE, DESFire, i-Class - OVER USB
651399-651362 Contactless SmartCard Enc. (Internal, 13.56Mhz) ISO 14443 (Type A/B), MIFARE, DESFire, i-Class - OVER Eth.
Add to Quote

Dual Sided with Laminator Interface and Encoding

# Name: Qty
651400 USB
651400-651570 USB + Ethernet
651400-651356 USB, Magnetic Stripe Enc. Standard (ISO 7811 (TrackI,II,III Read/Write), Hi-Co / Lo-Co Enc.)
651400-651358 USB, Magnetic Stripe Enc. Upper (ISO 7811 (TrackI,II,III Read/Write), Hi-Co / Lo-Co Enc.)
651400-651359 USB, Contact SmartCard Enc. (Internal) ISO 7816 (ID-1)
651400-651360 Contactless SmartCard Enc. (Internal, 13.56Mhz) ISO 14443 (Type A/B), MIFARE, DESFire, i-Class - OVER USB
651400-651362 Contactless SmartCard Enc. (Internal, 13.56Mhz) ISO 14443 (Type A/B), MIFARE, DESFire, i-Class - OVER Eth.
Add to Quote

Single Sided Interface and Encoding

# Name: Qty
651398 USB
651404 USB + Ethernet
651398-651356 USB, Magnetic Stripe Enc. Standard (ISO 7811 (TrackI,II,III Read/Write), Hi-Co / Lo-Co Enc.)
651398-651358 USB, Magnetic Stripe Enc. Upper (ISO 7811 (TrackI,II,III Read/Write), Hi-Co / Lo-Co Enc.)
651398-651359 USB, Contact SmartCard Enc. (Internal) ISO 7816 (ID-1)
651398-651360 Contactless SmartCard Enc. (Internal, 13.56Mhz) ISO 14443 (Type A/B), MIFARE, DESFire, i-Class - OVER USB
651398-651362 Contactless SmartCard Enc. (Internal, 13.56Mhz) ISO 14443 (Type A/B), MIFARE, DESFire, i-Class - OVER Eth.
Add to Quote

Single Sided Interface and Encoding Options

# Name: Qty
651398 IDP Smart-51 Single Sided USB
651404 IDP Smart-51 Single Sided USB + Ethernet
651398-651356 IDP Smart-51 Single Sided USB, Magnetic Stripe Enc. Standard (ISO 7811 (TrackI,II,III Read/Write), Hi-Co / Lo-Co Enc.)
651398-651358 IDP Smart-51 Single Sided USB, Magnetic Stripe Enc. Upper (ISO 7811 (TrackI,II,III Read/Write), Hi-Co / Lo-Co Enc.)
651398-651359 IDP Smart-51 Single Sided USB, Contact SmartCard Enc. (Internal) ISO 7816 (ID-1)
651398-651360 IDP Smart-51 Single Sided Contactless SmartCard Enc. (Internal, 13.56Mhz) ISO 14443 (Type A/B), MIFARE, DESFire, i-Class - OVER USB
651398-651362 IDP Smart-51 Single Sided Contactless SmartCard Enc. (Internal, 13.56Mhz) ISO 14443 (Type A/B), MIFARE, DESFire, i-Class - OVER Eth.
Add to Quote

Dual Sided Interface and Encoding Options

# Name: Qty
651399 IDP Smart-51 Dual Sided USB
651399-651570 IDP Smart-51 Dual Sided USB + Ethernet
651399-651356 IDP Smart-51 Dual Sided USB, Magnetic Stripe Enc. Standard (ISO 7811 (TrackI,II,III Read/Write), Hi-Co / Lo-Co Enc.)
651399-651358 IDP Smart-51 Dual Sided USB, Magnetic Stripe Enc. Upper (ISO 7811 (TrackI,II,III Read/Write), Hi-Co / Lo-Co Enc.)
651399-651359 IDP Smart-51 Dual Sided USB, Contact SmartCard Enc. (Internal) ISO 7816 (ID-1)
651399-651360 IDP Smart-51 Dual Sided Contactless SmartCard Enc. (Internal, 13.56Mhz) ISO 14443 (Type A/B), MIFARE, DESFire, i-Class - OVER USB
651399-651362 IDP Smart-51 Dual Sided Contactless SmartCard Enc. (Internal, 13.56Mhz) ISO 14443 (Type A/B), MIFARE, DESFire, i-Class - OVER Eth.
Add to Quote

Dual Sided with Laminator Interface and Encoding Options

# Name: Qty
651400 IDP Smart-51 Dual Sided with Laminator USB
651400-651570 IDP Smart-51 Dual Sided with Laminator USB + Ethernet
651400-651356 IDP Smart-51 Dual Sided with Laminator USB, Magnetic Stripe Enc. Standard (ISO 7811 (TrackI,II,III Read/Write), Hi-Co / Lo-Co Enc.)
651400-651358 IDP Smart-51 Dual Sided with Laminator USB, Magnetic Stripe Enc. Upper (ISO 7811 (TrackI,II,III Read/Write), Hi-Co / Lo-Co Enc.)
651400-651359 IDP Smart-51 Dual Sided with Laminator USB, Contact SmartCard Enc. (Internal) ISO 7816 (ID-1)
651400-651360 IDP Smart-51 Dual Sided with Laminator Contactless SmartCard Enc. (Internal, 13.56Mhz) ISO 14443 (Type A/B), MIFARE, DESFire, i-Class - OVER USB
651400-651362 IDP Smart-51 Dual Sided with Laminator Contactless SmartCard Enc. (Internal, 13.56Mhz) ISO 14443 (Type A/B), MIFARE, DESFire, i-Class - OVER Eth.
Add to Quote

Description

Fast and Reliable ID Card Printer

IDP’s new SMART-51 is the next generation of its mid-range ID Card Printer platform. The SMART-51 inherits the most successful and proven elements of the SMART-50 series printer to ensure the reliability. The upgraded SMART-51 will provide the most appropriate card issuance experience.

Faster Card Issuance

SMART-51 is upgraded with 10% faster print speed compared to the former SMART-50 series ID Card Printer.

  • Up to 225 cards / hour for single-sided color printing. (YMCKO, Back-side out mode)

Reliable Card Printer

SMART-51 is equipped with the Metal Frame body for the printing engine making sure to maintain long-lasting hardware structure and stable card printing quality.

Security

Optional physical lock can be used to secure the cards in the input hopper, ribbon and laminate film. Kensington lock slot can be equipped as an option.

User-friendly features

  • SMART-51 offers a larger card loading capacity up to 200 cards with its cover opened.
  • Removable back-side stacker (*Option) can stack up to 100 cards with faster printing speed.
  • Field upgradable back-side Flipper (for dual-sided printing) and Laminator (for dual-sided printing & laminating) can be easily installed.
  • SMART-51 can print on transparent cards with magnetic stripe.
  • Front-side Magnetic stripe encoding is supported.
  • The sleek modern appearance of the SMART-51 is a great addition to any desk.

Specifications

PRINTING

  • Print Mode: Single- or Dual-Sided
  • Print Type: Direct Dye-Sublimation
  • Print Area: Edge to Edge
  • Resolutions: 300dpi (Color & Mono), 600 & 1200dpi (Mono only)

CARD

  • Card Feeding: Automatic
  • Card Size: ISO CR80 or ISO CR79 (Option-Factory installed)
  • Card Thickness: 0.38mm (15mil) ~ 1.0mm (40mil)
  • Card Type: PVC, PET, Composite PVC

Print Speed

  • Monochrome: 5 sec./card (720 cards/hour)
  • YMCKO: Max. 17 sec./card (212 cards/hour)
  • YMCKOK: Max. 22 sec./card (164 cards/hour)

CAPACITY

  • Input Hopper: Card100 Cards / 200 Cards with cover open
  • Output Hopper: CardFront : 40 Cards / Rear : 100 Cards (Optional Rear-side Stacker)

LAMINATING (Option for Dual-Sided Printer)

  • Mode: Single & Dual
  • Film (Clear & Holographic): 0.6mil, 1.0mil
  • Speed (Simultaneous): 22 sec./card (YMCK, Single Lamination)
  • Speed (Simultaneous): 32 sec./card (YMCKK, Single Lamination)
  • Speed (One by One): 43 sec./card (YMCK, Single Lamination)
  • Speed (One by One): 53 sec./card (YMCKK, Single Lamination)

SYSTEM

  • Memory: 64MB RAM
  • Interface: 2 Line LCD / 2 LED Buttons
  • Supported Platforms: Microsoft Windows 7/ 8 /10, Mac OS, Linux
  • Communication: USB, Ethernet, WiFi (Option)
  • Power Supply: Free Voltage (AC 100/ 220V, 50~60Hz)
  • Power Consumption: 96W
  • Temperature: 15~35?
  • Humidity: 35~70%

SECURITY

  • Physical Lock: Input Hopper, Ribbon & Film (Option)
  • Station Itself: Kensington Lock (Option)

DIMENSIONS

  • Single-Sided: Milimeter: 165 (W) x 390 (L) x 210 (H) / Inch: 6.5 (W) x 15.4 (L) x 8.3 (H)
  • Dual-Sided: Milimeter: 165 (W) x 498 (L) x 210 (H) / Inch: 6.5 (W) x 19.6 (L) x 8.3 (H)
  • Laminating (Dual-Sided): Milimeter: 165 (W) x 675 (L) x 210 (H) / Inch: 6.5 (W) x 26.6 (L) x 8.3 (H)

WEIGHT

  • Single-Sided: Kg/Lbs: 4.5 / 10
  • Dual-Sided: Kg/Lbs: 5.2 / 11.5
  • Laminating (Dual-Sided): Kg/LbsApprox. 8.8 kg/19.4 lbs

ENCODING OPTION

  • Magnetic: ISO 7811 (Track I, II, III Read/ Write, HiCo/ LoCo), JIS II
  • Contact: ISO 7816 A/B/C Card, ISO 7816 1/2/3/4 Microprocessor Card
  • Contactless: ISO 14443 (Type A/ B), MIFARE, DESFIRE, iCLASS, ISO 18092(NFC), Felica

CERTIFICATIONS

  • Certifications: CB, CE, FCC, KC, CCC

Video
