General Specification
- Color printing module
- 300 dpi print head(11.8 dots/mm)
- USB connection
- 16 MB RAM
- Detachable out put hopper with a capacity of 100 cards
- 15 cards (0.76 mmor 30 mil)
- 1-Button and 4-LEDcontrol panel
- Printer color: Fire Red
- Automatic card thickness adjustment
Card loading modes
Automatic with feeder and/or hand-feed
Print modes
Color dye-sublimation and monochrome thermal transfer
Integrated ribbon saver for monochrome printing
Printing speeds
Personalization throughput will depend on card design and printer settings
Color (YMCKO): 40seconds per card
Monochrome: 7seconds per card
Supported platforms: Windows 7, XP and Vista 32 & 64 bits
Windows 2003 Server and Windows 2000 drivers available upon request - depending on system configuration
Supplied software: eMedia Trial - 30 days evaluation
Card types: All PVC, Composite PVC cards, PET, ABS1 & varnished cards
Card format: ISO CR-80 - ISO 7810 (53.98 mm x 85.60 mm - 3.375” x 2.125”)
Card thickness: 0.25 mm (10 mil) to 0.76 mm (30 mil)
Output hopper capacity: 15 cards (0.76 mm - 30 mil), 45 cards (0.25 mm - 10 mil)
Card feeder capacity: 100 cards (0.76 mm - 30 mil), 300 cards (0.25 mm - 10 mil)
Printer size: Height: 166 mm (6.53”), Length: 290 mm (11.42”) / 368 mm (14.49") with the detachable hopper, Width: 187 mm (7.36”)
Printer weight: 2.4 Kg (5.3 Lbs)
Connections: USB (Cable supplied)
Electrical : Power supply: 100-240 Volts AC, 1.5 or 1.8 A, 50-60 Hertz Printer: 24 Volts DC, 3 A
Environmental :
Min/Max operating temperature: 15° / 30°C (59° / 86° F)
Humidity: 20% to 65% non-condensing
Min/Max storage temperature: -5° / +70°C (23° / 158° F)
Storage humidity: 20% to 70% non-condensing
Operating ventilation: free air
Warranty: Printer, print head: 2 year warranty, unlimited numberof passes
