Print Method:Dye-Sublimation / Resin Thermal Transfer
Resolution:300 dpi (11.8 dots/mm) continuous tone
Colors:Up to 16.7 million / 256 shades per pixel
Print Ribbon Options:
• Full-color with resin black and overlay panel, YMCKO*, 250 prints • Full-color half-panel with resin black and overlay panel, YMCKO*, 350 prints • Full-color with two resin black panels and overlay panel, YMCKOK*, 200 prints • Full-color with fluorescing, resin black and overlay panel, YMCFKO*, 200 prints • Dye-sublimation black and overlay panel, BO*, 500 prints • Resin black, and overlay panel, KO, 500 prints • Resin black, green, blue, red, white, 1,000 prints; silver and gold, 500 prints
Printer Speed:
• 7 seconds per card (K) Print Speed: • 12 seconds per card (KO)
• 27 seconds per card (YMCKO) • 35 seconds per card (YMCKOK)
Accepted Standard Card Sizes:• CR-80 (3.375"L x 2.125"W / 85.6mmL x 54mmW) • CR-79 Adhesive Back (3.313"L x 2.063"W / 84.1mmL x 52.4mmW)
Print Area:• CR-80 edge-to-edge (3.36"L x 2.11"W / 85.3mmL x 53.7mmW) • CR-79 (3.3"L x 2.04"W / 83.8mmL x 51.8mmW)
Accepted Card Thickness:.009" – .040" / 9 mil – 40 mil / .229mm – 1.016mm
Accepted Card Types:PVC or polyester cards with polished PVC finish; monochrome resin required for100% polyester cards; optical memory cards with PVC finish
Input Hopper Card Capacity:100 cards (.030" / .762mm)
Output Hopper Card Capacity:Up to 30 cards (.030" / .762mm)
Reject Hopper Card Capacity:15 cards (.030" / .762mm)
Card Cleaning:Card cleaning roller integrated into ribbon cartridge; cleaning roller is automatically replaced with each ribbon change
Memory:2MB RAM
Software Drivers:Windows 2000 / XP / Vista (32 bit) / Server 2003; Linux
Interface:USB 1.1 (USB 2.0 compatible), optional Ethernet with internal print server
Operating Temperature:65° to 80° F / 18° to 27° C
Humidity:20 – 80% non-condensing
Dimensions: 7.9"H x 13.62"W x 8.14"D / 201mmH x 346mmW x 207mmD
Weight: 8 lbs. / 3.63 kg
Agency Listings: Safety: UL 60950-1, CSA C22.2 (60950-1), and CE • EMC: FCC Class A, CRC c1374, CE (EN 55022 Class A, EN 55024)
Supply Voltage:100-240 VAC, 3.3 A
Supply Frequency:50 Hz / 60 Hz
Warranty:• Printer – Two years including free loaner printer in the first year. Printhead – Two years, unlimited pass with UltraCardTM Cards
